Parts and accessories

The use of a permeate flow control is strongly recommended during upstream clarification of target material. Permeate flow control rate is dependent on the process flux (LMH) and surface area. Detailed information about Permeate flow control kit (56-4107-73), is available below.

Suitable peristaltic pump (56-4106-53) for permeate flow control, flow rates 5.4 ml/min - 2 liter/min.

Feed reservoir (56-4107-67 or 56-4107-70) has to be ordered separately.

FlexStand low void volume system can be converted to FlexStand standard system, suitable for Housing 5-9, by using a conversion kit.

For countries using 220 V power, power cords have to be ordered separately for the pump above and system.

After use, store the cartridge with liquid inside using blank off cap, gasket and clamp on the feed and retentate ports.

Seal the permeate port with a short piece of tubing i.d. 13 mm, which is secured using snapper clamp or cable tie wrap. The end is closed with snapper clamp, pinch valve or cable tie wrap.
