Pall™ Ultipor™ N66 filter capsules and filter discs

Ultipor™ N66 particulate and bioburden reduction filter capsules, part of our Pall filtration portfolio, are specifically engineered for fine filtration, prefiltration and bioburden reduction of a wide range of pharmaceutical and biological liquids. They incorporate versatile Ultipor™ N66 pure Nylon 6,6 membranes and provide reliable, economical and efficient particulate and bioburden removal.

1. Application

Bioburden removal

Particulate removal

2. Absolute rating

0.2 μm

0.45 μm

0.65 μm

0.8 μm

1.2 μm

4. Filter format

Filter capsule

Filter disc

Ultipor N66 bioburden filter capsules and filter discs

To buy, choose your product.

Price includes standard shipping and handling

Overview

Ultipor™ N66 particulate and bioburden reduction filter capsules, part of our Pall filtration portfolio, are specifically engineered for fine filtration, prefiltration and bioburden reduction of a wide range of pharmaceutical and biological liquids. They incorporate versatile Ultipor™ N66 pure Nylon 6,6 membranes and provide reliable, economical and efficient particulate and bioburden removal.

Different membrane pore sizes to support range of applications.
Intrinsically water wettable.
Fixed pores, non-shedding.
Resin and surfactant-free with low filter extractables.
Broad solvent compatibility.
High protein recovery from most protein solutions.
Made without intentionally using PFAS

Microbial and particulate removal ratings

There are seven membrane grades available that achieve different microbial or particulate removal ratings. These are summarized in the table below.

Membrane grade	Removal rating
NN	1.2 μm particulate rated
NH	0.8 μm particulate rated
NK	0.65 μm particulate rated
NB	0.45 μm microbial-rated (Typical Serratia marcescens T_R > 10^{4 – 6})
NX, NL	0.45 μm microbial-rated (Lot samples retain > 107 /cm² Serratia marcescens)
NA	0.2 μm microbial-rated (Typical Brevundimonas diminuta T_R > 10^{4 – 6})

Quality and Bio-Safety

Manufactured for use in conformance with cGMP.
ISO 9000 Certified Quality System.
Certificate of Test provided
FDA-listed materials per 21 CFR

Biological Tests

Meets USP Biological Reactivity test, in vivo, for Class VI-121 °C Plastics

Effluent Quality Tests*

Meets cleanliness per USP Particulates in Injectables
Non-fiber-releasing
Non-Pyrogenic per USP.
Meets total organic carbon and water conductivity per USP Purified Water, pH per USP Sterile Purified Water.

*Per lot sample soak or rinse-up flush aliquots.

Product specifications

Showing 39 products

DFA3001NXP

Pall™ Ultipor™ N66 DFA capsule, NX grade

Bioburden removal

0.45 μm

800 cm²

Filter capsule

In stock25 available

263.00 USD

DFA4001NXP

Pall™ Ultipor™ N66 DFA capsule, NX grade

Bioburden removal

0.45 μm

800 cm²

Filter capsule

In stock106 available

240.00 USD

NP7NBP1G

Pall™ Ultipor™ N66 Kleenpak™ Nova 20 inch capsule, in-line style, NB grade, 1-1½ in (25-38 mm) sanitary flange connections

Bioburden removal

0.45 μm

1.64 m²

Filter capsule

In stock6 available

1,235.00 USD

KA1NLP2

Pall™ Ultipor™ N66 Kleenpak™ KA1 capsule, NL grade, 6 to 13 mm stepped hosebarb connections

Bioburden removal

0.45 μm

500 cm²

Filter capsule

Selling fast4 available

243.00 USD

KA2NLP1

Pall™ Ultipor™ N66 Kleenpak™ KA2 capsule, NL grade, 1-1½ in (25-38 mm) sanitary flange connections

Bioburden removal

0.45 μm

900 cm²

Filter capsule

Selling fast1 available

284.00 USD

KA3NLP1

Pall™ Ultipor™ N66 Kleenpak™ KA3 capsule, NL grade, 1-1½ in (25-38 mm) sanitary flange connections

Bioburden removal

0.45 μm

2200 cm²

Filter capsule

Selling fast5 available

335.00 USD

KA4NLP1

Pall™ Ultipor™ N66 Kleenpak™ KA4 capsule, NL grade, 1-1½ in (25-38 mm) sanitary flange connections

Bioburden removal

0.45 μm

5100 cm²

Filter capsule

Selling fast2 available

421.00 USD

NP6NXP1G

Pall™ Ultipor™ N66 Kleenpak™ Nova 20 inch capsule, in-line style, NX grade, 1-1½ in (25-38 mm) sanitary flange connections

Bioburden removal

0.45 μm

0.47 m²

Filter capsule

Selling fast2 available

809.00 USD

FTKNB

Pall™ Ultipor™ N66 Filter test kit, NB grade

Bioburden removal

0.45 μm

14 cm²

Filter disc

Stock on request

78.65 USD

FTKNK

Pall™ Ultipor™ N66 Filter test kit, NK grade

Particulate removal

0.65 μm

14 cm²

Filter disc

Stock on request

25.08 USD

FTKNL

Pall™ Ultipor™ N66 Filter test kit, NL grade

Bioburden removal

0.45 μm

14 cm²

Filter disc

Stock on request

29.59 USD

FTKNN

Pall™ Ultipor™ N66 Filter test kit, NN grade

Particulate removal

1.2 μm

14 cm²

Filter disc

Stock on request

74.51 USD

FTKNX

Pall™ Ultipor™ N66 Filter test kit, NX grade

Bioburden removal

0.45 μm

14 cm²

Filter disc

Stock on request

92.84 USD

KA1NLP1

Pall™ Ultipor™ N66 Kleenpak™ KA1 capsule, NL grade, 1-1½ in (25-38 mm) sanitary flange connections

Bioburden removal

0.45 μm

500 cm²

Filter capsule

Stock on request

241.00 USD

KA2NAP1S

Pall™ Ultipor™ N66 Kleenpak™ KA2 capsule, NA grade, 1-1½ in (25-38 mm) sanitary flange connections, pre-sterilized

Bioburden removal

0.2 μm

930 cm²

Filter capsule

Stock on request

306.00 USD

KA3NBP1

Pall™ Ultipor™ N66 Kleenpak™ KA3 capsule, NB grade, 1-1½ in (25-38 mm) sanitary flange connections

Bioburden removal

0.45 μm

2430 cm²

Filter capsule

Stock on request

258.00 USD

KA3NBP6

Pall™ Ultipor™ N66 Kleenpak™ KA3 capsule, NB grade, 13 mm hose barb connections

Bioburden removal

0.45 μm

2430 cm²

Filter capsule

Stock on request

256.00 USD

KA3NLP6

Pall™ Ultipor™ N66 Kleenpak™ KA3 capsule, NL grade, 13 mm hose barb connections

Bioburden removal

0.45 μm

2200 cm²

Filter capsule

Stock on request

245.00 USD

KA3NNP16G

Pall™ Ultipor™ N66 Kleenpak™ KA3 capsule, NN grade, 1-1½ in (25-38 mm) sanitary flange inlet, 13 mm hose barb outlet connections

Particulate removal

1.2 μm

2430 cm²

Filter capsule

Stock on request

410.00 USD

KA3NNP1G

Pall™ Ultipor™ N66 Kleenpak™ KA3 capsule, NN grade, 1-1½ in (25-38 mm) sanitary flange connections

Particulate removal

1.2 μm

2430 cm²

Filter capsule

Stock on request

56.03 USD

NHG14225

Pall™ Ultipor™ N66 Filter disc 142 mm, NH grade, pack of 25

Particulate removal

0.8 μm

Holder dependant

Filter disc

Stock on request

349.00 USD

NHG29325

Pall™ Ultipor™ N66 Filter disc 293 mm, NH grade, pack of 25

Particulate removal

0.8 μm

Holder dependant

Filter disc

Stock on request

680.00 USD

NNG14225

Pall™ Ultipor™ N66 Filter disc 142 mm, NN grade, pack of 25

Particulate removal

0.8 μm

Holder dependant

Filter disc

Stock on request

310.00 USD

NP6NBP1G

Pall™ Ultipor™ N66 Kleenpak™ Nova 10 inch capsule, in-line style, NB grade, 1-1½ in (25-38 mm) sanitary flange connections

Bioburden removal

0.45 μm

0.82 m²

Filter capsule

Stock on request

605.00 USD

NP6NLP16G

Pall™ Ultipor™ N66 Kleenpak™ Nova 10 inch capsule, in-line style, NL grade, 1-1½ in (25-38 mm) sanitary flange inlet, 13 mm hose barb outlet connections

Bioburden removal

0.45 μm

0.82 m²

Filter capsule

Stock on request

965.00 USD

NP7NAP1S

Pall™ Ultipor™ N66 Kleenpak™ Nova 20 inch capsule, in-line style, NA grade, 1-1½ in (25-38 mm) sanitary flange connections

Bioburden removal

0.2 μm

1.68 m²

Filter capsule

Stock on request

1,418.00 USD

NP7NBP6G

Pall™ Ultipor™ N66 Kleenpak™ Nova 20 inch capsule, in-line style, NB grade, 13 mm hose barb connections

Bioburden removal

0.45 μm

1.64 m²

Filter capsule

Stock on request

1,362.00 USD

NT6NBP1G

Pall™ Ultipor™ N66 Kleenpak™ Nova 10 inch capsule, T style, NB grade, 1-1½ in (25-38 mm) sanitary flange connections

Bioburden removal

0.45 μm

0.82 m²

Filter capsule

Stock on request

770.00 USD

NT6NLP1G

Pall™ Ultipor™ N66 Kleenpak™ Nova 10 inch capsule, T style, NL grade, 1-1½ in (25-38 mm) sanitary flange connections

Bioburden removal

0.45 μm

0.82 m²

Filter capsule

Stock on request

866.00 USD

NT6NXP1G

Pall™ Ultipor™ N66 Kleenpak™ Nova 10 inch capsule, T style, NX grade, 1-1½ in (25-38 mm) sanitary flange connections

Bioburden removal

0.45 μm

0.47 m²

Filter capsule

Stock on request

180.94 USD

NT7NAP1G

Pall™ Ultipor™ N66 Kleenpak™ Nova 10 inch capsule, T style, NA grade, 1-1½ in (25-38 mm) sanitary flange connections

Bioburden removal

0.2 μm

1.68 m²

Filter capsule

Stock on request

1,456.00 USD

NT7NBP1G

Pall™ Ultipor™ N66 Kleenpak™ Nova 10 inch capsule, T style, NB grade, 1-1½ in (25-38 mm) sanitary flange connections

Bioburden removal

0.45 μm

1.64 m²

Filter capsule

Stock on request

1,457.00 USD

NT7NXP1G

Pall™ Ultipor™ N66 Kleenpak™ Nova 10 inch capsule, T style, NX grade, 1-1½ in (25-38 mm) sanitary flange connections

Bioburden removal

0.45 μm

0.94 m²

Filter capsule

Stock on request

1,369.00 USD

NT8NBP1G

Pall™ Ultipor™ N66 Kleenpak™ Nova 10 inch capsule, T style, NB grade, 1-1½ in (25-38 mm) sanitary flange connections

Bioburden removal

0.45 μm

2.46 m²

Filter capsule

Stock on request

1,672.00 USD

NT8NLP1G

Pall™ Ultipor™ N66 Kleenpak™ Nova 10 inch capsule, T style, NL grade, 1-1½ in (25-38 mm) sanitary flange connections

Bioburden removal

0.45 μm

2.46 m²

Filter capsule

Stock on request

1,995.00 USD

NT8NXP1G

Pall™ Ultipor™ N66 Kleenpak™ Nova 10 inch capsule, T style, NX grade, 1-1½ in (25-38 mm) sanitary flange connections

Bioburden removal

0.45 μm

1.41 m²

Filter capsule

Stock on request

2,435.00 USD

NX09025

Pall™ Ultipor™ N66 Filter disc 90 mm, NX grade, pack of 25

Bioburden removal

0.45 μm

Holder dependant

Filter disc

Stock on request

158.20 USD

NX14225

Pall™ Ultipor™ N66 Filter disc 142 mm, NX grade, pack of 25

Bioburden removal

0.45 μm

Holder dependant

Filter disc

Stock on request

354.00 USD

NX29325

Pall™ Ultipor™ N66 Filter disc 293 mm, NX grade, pack of 25

Bioburden removal

0.45 μm

Holder dependant

Filter disc

Stock on request

488.00 USD
